Air Cooling Conveyor
Air Cooling Conveyor
The air cooling conveyor cools down items as it moves them along. This is especially useful right after items have been coated and are still hot.
It is primarily used for blowing cool air on products with elevated temperatures after they have passed through a roller-coating application. This cooling is crucial in maintaining the integrity and quality of the finished products.
| Model | Working width (mm) | Working thickness (mm) | Min. working length (mm) | Feeding speed (m/min) | Feeding power (kW) |
| 600 | 2-80 | 500 | 0-10 | 0.75 | |
| 900 | 2-80 | 500 | 0-10 | 0.75 | |
| 1300 | 2-80 | 500 | 0-10 | 0.75 | |
| 1650 | 2-80 | 500 | 0-10 | 1.5 | |
| 1950 | 2-80 | 500 | 0-10 | 1.5 | |
| 2200 | 2-80 | 500 | 0-10 | 2.2 | |
| 2400 | 2-80 | 500 | 0-10 | 2.2 | |
| 2600 | 2-80 | 500 | 0-10 | 2.2 |
Note: The length of the equipment can be designed according to the specific needs of the process and the size of the facility.
As products pass through the conveyor, multiple fans at the front end blow room-temperature air, effectively reducing the temperature of the items. This conveyor is a crucial component in maintaining quality and safety in coating lines, especially when handling heat-sensitive materials.
